16 Lane Automatic Counting Machine

It can count while pack all kinds of capsules, tablets and gummies into a bottle, which is suitable for scientific research institutions, hospitals, pharmaceutical factories, health products, factory production packaging. And it can also integrate with cartoning machine, labeling machine, etc.

Specification:

Up to 80 bottles/mins

accuracy rate > 99.8%

7 Days Fast Delivery

Suitable for 3-25mm capsule/tablet/gummy

How 16 Lane Automatic Counting Machine Works

Except for just simply counting and filling tablets and capsules into bottles, Rich Packing automatic counting machine is equipped with working sections and technologies to ensure a smooth and efficient production process.

Main Features

Capacity : 20-80 bottles/min
Accuracy rate >99.8%
Applicable target #000-5 capsule, soft capsule, Ø 3-25 tablet,shaped,sugarcoated tablet, pill
Filling range 1-9999 grains (tablets) adjustable
Applicable bottle type 10-500ml round, square bottle
Voltage 380/220V 50Hz(customizable)
Power 1.2KW
Weight 550 kg
Outline dim.(mm) 1600×1650×1500mm

1. High accuracy.The accuracy rate of several canned grains is more than 99.8%, which is higher than the industry standard.

2. The flip-flop subassembly mechanism obtains the national patent, does not damage the material when opening and closing.

3. Good stability.Using the electronic counting technology of high dust resistance, it can still operate normally in high dust environment.

4. Strong compatibility, wide scope of application.All kinds of tablets, capsules (transparent or opaque hard capsules, soft capsules, pills, etc.) can be counted and canned.

5. Multistage vibration design.Large size, irregular, high viscosity materials can be effectively separated, accurate count.

6. High intelligence.With the bottle, materials, all kinds of online fault monitoring function, and automatic alarm.

7. Special feeding varieties can be customized according to actual needs.

8. The quality is reliable.The machine adopts stainless steel 304, material contact part uses stainless steel 316 material.

9. Equiped with dust collection box, centralized dust collection, reduce pollution.

Main Parts
