ZP-17D Rotary Tablet Press Machine

ZP-17D Rotary Tablet Press Machine

Also called as multi-station tablet press, can efficiently press powder and granules into tablets with diverse diameters and thicknesses. Dan dengan customized dies, Bahan -bahannya bahkan dapat ditekan ke berbagai bentuk untuk kebutuhan Anda, seperti bulat, segi tiga, batang inti, dan tablet berbentuk khusus.

Spesifikasi:

Up to 37,800pcs/h

Max. dia. of tablet 20mm

Max. pressure 100kn

15 Days Fast Delivery

Permintaan Penawaran

Cara kerjanya?

Apart from just simply pressing the powder into a tablet, Ruida Packing rotary tablet press machine is equipped with working sections and technologies to ensure a smooth and efficient production process.

Fitur utama

Model	ZP-11D	ZP-15D	ZP-17D	ZP-19D	ZP-21D
Max. Pressure	100kn	80 kn	60kn
Max. Adalah. tablet	40mm	25 mm	20 mm	13 mm	12 mm
Max. Kapasitas produksi	13200 pc/h	27000 pc/h	30600 pc/h	34200 pc/h	37800 pc/h
Power	3.0kw
voltage	380/220V 50Hz（customizable）
Weight	1000kg
Size	8906501680mm

1. This machine has high pressure and large tableting range, and can compress tablets of various shapes, such as ordinary, irregular and circular shapes.

2. ZP-17D series tablet press is equipped with pressure overload protection device, once overloaded, it will automatically stop to avoid equipment damage.

3. This tablet press is equipped with a turntable double suction, with six suction ports up and down, with good powder removal effect and a clean surface of the turntable.

4. The turntable is made of nodular cast iron QT500, pressed by solid bar material, with strong hardness, heat resistance, wear resistance and good system stability.

5. The power part is sealed and placed at the bottom to prevent contact with materials and reduce secondary pollution.

6. Low noise. The upper and lower rails are made of cast steel. The running arc and angular position of the rails are designed scientifically. The large-angle linear structure makes the mold run smoothly and has low noise.

7. The mold is made of GCR15 material, which has strong hardness and good corrosion resistance.
