260W Automatic Horizontal Cartoning Machine

Our cartoning machine guaranteed for life, can unfold the box and fill it with bottles, sachets, and blister plates. It may also be linked to a counting machine, آلة التعبئة والتغليف نفطة, and other similar machines to boost workplace automation.

تخصيص:

يصل إلى 260 carton/min

Appplicable For Bister Plate, زجاجة, Sachet Etc

20 أيام التسليم السريع

اطلب اقتباس

How It Works

Can pack products of various specifications on one machine.High degree of automation,from feeding,suction carton,forming,on line transmission,folding of leaflet(1-4 folds),material testing,products and leaflet pushing into carton，printing batch number,with top fold flaps,carton sealing(mechanical sealing or hot melt glue),lack of material detection and rejection all automatically completed.

الخصائص الرئيسية

السعة الإنتاجية :	260 carton/min
size range of carton :	size range of carton:L(70-180)W(35-80)ح(12-50)mm
Requirements of instructions :	size range of instructions:L(80-250)*W(90-170)mm
	range of folding times of instructions:1-4 fold
	instructions weight:60-70g/㎡
Total power :	5.0 KW
Power supply :	220/380فولت 50 هرتز (قابل للتخصيص)
Net weight of machine :	3400kg
Overall size of machine :	680016001860mm

1.The machine body is made of stainless steel or nickel-chromium plated material, and the welding position is tempered. It has the advantages of corrosion resistance, non-toxicity, harmlessness and durability.

2.High intelligence.Detection points are distributed in various workstation, such feeding , loading capacity detection , packaging into conveyor belt detection, quantity of packages inspection, carton in place inspection and etc.

3.The machine adopts a rotating quadrilateral double planetary wheel structure to open the carton, and have two pre-forming devices to ensure the forming effect of the carton and improve the working efficiency.

4.The main motor, sensor, frequency converter and pneumatic components of the cartoning machine all adopt international famous brand products with stable performance and guaranteed quality.

5. All spare parts of our cartoning packing machine are coded to facilitate the daily maintenance of customers.

6. It has high integration and can be connected with tail sealing machine, aluminum plastic blister packaging machine and wrapping machine according to production requirements.
