ZP-29D Rotary Tablet Press Machine

ZP-29D Rotary Tablet Press Machine

Auch als Multistation-Tablettenpresse bezeichnet, kann Pulver und Granulat effizient zu Tabletten mit unterschiedlichen Durchmessern und Dicken pressen. Und mit individuellen Stanzformen, Die Zutaten können je nach Bedarf sogar in verschiedene Formen gepresst werden, wie rund, Dreieck, Kernstab, und speziell geformte Tabletten.

Spezifikation:

Up to 110000pcs/h

Max. Ist. of tablet 24mm

Max. Druck 100kn

15 Tageschnelle Lieferung

Fordern Sie ein Angebot an

Wie es funktioniert?

Abgesehen davon, dass man das Pulver einfach zu einer Tablette presst, Ruida Packing rotary tablet press machine is equipped with working sections and technologies to ensure a smooth and efficient production process.

Haupteigenschaften

Modell :	ZP-29D
Max. Produktionskapazität :	110000 Stk/h
Max. Pressure :	100KN
Max. Ja. des Tablets :	24mm
Max. Depth of Filling :	24mm
Max. Thickness of Tablet :	12mm
Motor :	5.5kw
Power supply :	220/380V 50Hz (anpassbar)
Weight of Machine :	1600 kg
Overall Size of Machine :	1040×910×1690mm

1. It meets the requirements of GMP. The whole shell is made of stainless steel, and the chamber is separated from the outside environment by the organic glass, with good sealing.

2. The turntable is made of nodular cast iron and strictly implemented for 12 months, which is hard, wearable, non-toxic and smooth, which fully meets the requirements of GMP.

2. The upper and downlink rail motion adopts the cosine curve, and the acceleration is 0, no jump and more stable operation.

3. With pressure overload protection device. It will start the overload protection through the spring pressure, alarm lights, automatic stop running.

4. The principle of eccentric torque is used to protect the die and machine. Compared with the hydraulic overload protection, it has a fast reaction speed and no oil pollution

5. The independent modularization of the transmission system is set under the main body of the machine, and it can effectively avoid the trace contaminant drugs produced by the friction of the machine running.

6. Lower pressure wheel shaft and the lower rail guide are installed with the casting subtraction structure (new patent), which is convenient for disassemble, maintenance and replacement.
